Spike Tab Cutting Template for Laser Projects

This is a spike tab cutting template designed to produce a small tab-style connector for laser-cut projects. The pattern creates a spike-shaped tab part you can use to join or lock cut pieces together.

It’s intended as a joinery and prototyping element — handy when you need a tab-style connector that fits into a mating slot or adds a simple friction fit in small assemblies.

The template works well for quick prototypes, test fixtures, jig parts, and craft models. Try cutting from wood-based sheet stock or other cuttable board and perform a test fit before final runs.

Provided as a DXF vector file, the outlines import into most cutting and CAM software. Clean vectors make scaling, nesting, and arranging parts simple so you can adjust size and fit.

Hobby makers, teachers, and small workshops can use this spike tab in experiments, classroom projects, or low-volume builds. Download the DXF file for free and run a test cut to confirm fit.
